Part
Number |
集电通
JDT FUSE |
IH
(A) |
IT
(A) |
VMAX
(VDC) (VAC RMS) |
IMAX
(DCADC) (ACARMS) |
PD TYP
(W) |
Max Time
-to-trip (A) (S) |
RMIN
(Ω) |
RMAX
(Ω) |
R1MAX
(Ω) |
Lead Size
[mm2(AWG)] |
|
RUSBF090
|
A16-090
|
0.90
|
1.8
|
16
|
40
|
0.6
|
8.0 1.2
|
0.070
|
0.120
|
0.180
|
[0.205mm2(24)]
|
|
RUSBF110
|
A16-110
|
1.10
|
2.2
|
16
|
40
|
0.7
|
8.0 2.3
|
0.050
|
0.095
|
0.140
|
[0.205mm2(24)]
|
|
RUSBF135
|
A16-135
|
1.35
|
2.7
|
16
|
40
|
0.8
|
8.0 4.5
|
0.040
|
0.074
|
0.112
|
[0.205mm2(24)]
|
|
RUSBF160
|
A16-160
|
1.60
|
3.2
|
16
|
40
|
0.9
|
8.0 9.0
|
0.030
|
0.061
|
0.110
|
[0.205mm2(24)]
|
|
RUSBF185
|
A16-185
|
1.85
|
3.7
|
16
|
40
|
1.0
|
8.0 10.0
|
0.030
|
0.051
|
0.090
|
[0.205mm2(24)]
|
|
RUSBF250
|
A16-250
|
2.50
|
5.0
|
16
|
40
|
1.2
|
8.0 40.0
|
0.020
|
0.036
|
0.060
|
[0.205mm2(24)]
|
|
RGEF250
|
A16-250
|
2.5
|
4.7
|
16
|
100
|
1.0
|
12.5 5.0
|
0.0220
|
0.0350
|
0.0530
|
[0.205mm2(24)]
|
|
RGEF300
|
A16-300
|
3.0
|
5.1
|
16
|
100
|
2.3
|
15.0 1.0
|
0.0380
|
0.0645
|
0.0975
|
[0.520mm2(20)]
|
|
RGEF400
|
A16-400
|
4.0
|
6.8
|
16
|
100
|
2.4
|
20.0 1.7
|
0.0210
|
0.0390
|
0.0600
|
[0.520mm2(20)]
|
|
RGEF500
|
A16-500
|
5.0
|
8.5
|
16
|
100
|
2.6
|
25.0 2.0
|
0.0150
|
0.0240
|
0.0340
|
[0.520mm2(20)]
|
|
RGEF600
|
A16-600
|
6.0
|
10.2
|
16
|
100
|
2.8
|
30.0 3.3
|
0.0100
|
0.0190
|
0.0280
|
[0.520mm2(20)]
|
|
RGEF700
|
A16-700
|
7.0
|
11.9
|
16
|
100
|
3.0
|
35.0 3.5
|
0.0077
|
0.0131
|
0.0200
|
[0.520mm2(20)]
|
|
RGEF800
|
A16-800
|
8.0
|
13.6
|
16
|
100
|
3.0
|
40.0 5.0
|
0.0056
|
0.0110
|
0.0175
|
[0.520mm2(20)]
|
|
RGEF900
|
A16-900
|
9.0
|
15.3
|
16
|
100
|
3.3
|
45.0 5.5
|
0.0047
|
0.0091
|
0.0135
|
[0.520mm2(20)]
|
|
RGEF1000
|
A16-1000
|
10.0
|
17.0
|
16
|
100
|
3.6
|
50.0 6.0
|
0.0040
|
0.0070
|
0.0102
|
[0.520mm2(20)]
|
|
RGEF1100
|
A16-1100
|
11.0
|
18.7
|
16
|
100
|
3.7
|
55.0 7.0
|
0.0037
|
0.0060
|
0.0089
|
[0.520mm2(20)]
|
|
RGEF1200
|
A16-1200
|
12.0
|
20.4
|
16
|
100
|
4.2
|
60.0 7.5
|
0.0033
|
0.0057
|
0.0086
|
[0.823mm2(18)]
|
|
RGEF1400
|
A16-1400
|
14.0
|
23.8
|
16
|
100
|
4.6
|
70.0 9.0
|
0.0026
|
0.0043
|
0.0064
|
[0.823mm2(18)]
|
|
RHEF200
|
A16-200
|
2.0
|
3.8
|
16
|
100
|
1.4
|
10.0 4.3
|
0.0450
|
0.07400
|
0.1100
|
[0.205mm2(24)]
|
|
RHEF300
|
A16-300
|
3.0
|
6.0
|
16
|
100
|
3.0
|
15.0 5.0
|
0.0330
|
0.05300
|
0.0790
|
[0.520mm2(20)]
|
|
RHEF400
|
A16-400
|
4.0
|
7.5
|
16
|
100
|
3.3
|
20.0 5.0
|
0.0240
|
0.04000
|
0.0600
|
[0.520mm2(20)]
|
|
RHEF450
|
——
|
4.5
|
7.8
|
16
|
100
|
3.6
|
22.5 3.0
|
0.0220
|
0.03600
|
0.0540
|
[0.520mm2(20)]
|
|
RHEF550
|
——
|
5.5
|
10.0
|
16
|
100
|
3.5
|
27.5 6.0
|
0.0150
|
0.02500
|
0.0370
|
[0.520mm2(20)]
|
|
RHEF600
|
A60-600
|
6.0
|
10.8
|
16
|
100
|
4.1
|
30.0 5.0
|
0.0130
|
0.02150
|
0.0320
|
[0.520mm2(20)]
|
|
RHEF650
|
——
|
6.5
|
12.0
|
16
|
100
|
4.1
|
32.5 7.0
|
0.0110
|
0.01750
|
0.0260
|
[0.520mm2(20)]
|
|
RHEF700
|
A60-700
|
7.0
|
13.0
|
16
|
100
|
4.0
|
35.0 7.0
|
0.0100
|
0.01640
|
0.0250
|
[0.520mm2(20)]
|
|
RHEF750
|
——
|
7.5
|
13.1
|
16
|
100
|
4.5
|
37.5 7.0
|
0.0094
|
0.01530
|
0.0220
|
[0.520mm2(20)]
|
|
RHEF800
|
A60-800
|
8.0
|
15.0
|
16
|
100
|
4.2
|
40.0 8.0
|
0.0080
|
0.01350
|
0.0200
|
[0.520mm2(20)]
|
|
RHEF900
|
A60-900
|
9.0
|
16.5
|
16
|
100
|
5.0
|
45.0 10.0
|
0.0074
|
0.01200
|
0.0170
|
[0.520mm2(20)]
|
|
RHEF1000
|
A60-1000
|
10.0
|
18.5
|
16
|
100
|
5.3
|
50.0 9.0
|
0.0062
|
0.01050
|
0.0150
|
[0.520mm2(20)]
|
|
RHEF1100
|
A60-1100
|
11.0
|
20.0
|
16
|
100
|
5.5
|
55.0 11.0
|
0.0055
|
0.00900
|
0.0130
|
[0.520mm2(20)]
|
|
RHEF1300
|
A60-1300
|
13.0
|
24.0
|
16
|
100
|
6.9
|
65.0 13.0
|
0.0041
|
0.00690
|
0.0100
|
[0.823mm2(18)]
|
|
RHEF1400
|
A60-1400
|
14.0
|
27.0
|
16
|
100
|
6.9
|
70.0 13.0
|
0.0030
|
0.00600
|
0.0090
|
[0.823mm2(18)]
|
|
RHEF1500
|
——
|
15.0
|
28.0
|
16
|
100
|
7.0
|
75.0 20.0
|
0.0032
|
0.00613
|
0.0092
|
[0.823mm2(18)]
|
