Part Number |
Rated Current (A) |
Max Voltage Rating(V) |
Interrupting Rating |
Nominal Cold Resistance (ohms） |
Nominal Melting I2t(A2sec) |
| JFC2410-0500FS | 0.50 | 250V | 50A@250V | 0.4200 | 0.0795 |
| JFC2410-0750FS | 0.75 | 0.2450 | 0.185 | ||
| JFC2410-1100FS | 1.00 | 0.1530 | 0.459 | ||
| JFC2410-1150FS | 1.50 | 0.0630 | 0.853 | ||
| JFC2410-1200FS | 2.0 | 0.0367 | 0.530 | ||
| JFC2410-1250FS | 2.50 | 0.0286 | 1.029 | ||
| JFC2410-1300FS | 3.00 | 0.0227 | 1.650 | ||
| JFC2410-1350FS | 3.50 | 0.0200 | 2.469 | ||
| JFC2410-1400FS | 4.00 | 0.0160 | 3.152 | ||
| JFC2410-1500FS | 5.00 | 0.0125 | 5.566 | ||
| JFC2410-1600FS | 6.00 | 0.0108 | 8.670 | ||
| JFC2410-1630FS | 6.30 | 0.0096 | 9.170 | ||
| JFC2410-1700FS | 7.00 | 0.0090 | 10.32 | ||
| JFC2410-1800FS | 8.00 | 0.0077 | 20.23 | ||
| JFC2410-2100FS | 10.0 | 35A@250V | 0.0056 | 26.46 | |
| JFC2410-2120FS | 12.0 | 0.0049 | 47.97 | ||
| JFC2410-2150FS | 15.0 | 0.0037 | 97.82 |
