主页 > 产品中心 > Bussmann/巴斯曼 > 贴片保险丝 >
|
Catalog Symbol |
Current Rating (amps) |
Voltage Rating (Vdc) |
Interrupting Rating* (amps) |
Resistance (Ω)** Typical |
Typical Melt (I2t)† DC |
Typical Voltage Drop (mV) |
Alpha Marking |
| CC12H750mA | 0.75 | 63 | 50 | 0.780 | 0.15 | 840 | E |
| CC12H1A | 1 | 63 | 50 | 0.470 | 0.18 | 490 | H |
| CC12H1.5A | 1.5 | 63 | 50 | 0.218 | 0.4 | 355 | K |
| CC12H2A | 2 | 63 | 50 | 0.133 | 1.1 | 305 | N |
| CC12H2.5A | 2.5 | 63 | 50 | 0.079 | 1.7 | 240 | O |
| CC12H3A | 3 | 63 | 50 | 0.049 | 2.2 | 185 | P |
| CC12H3.5A | 3.5 | 63 | 50 | 0.037 | 2.7 | 180 | R |
| CC12H4A | 4 | 63 | 50 | 0.033 | 3.2 | 169 | S |
| CC12H4.5A | 4.5 | 32 | 100 | 0.028 | 4.2 | 160 | X |
| CC12H5A | 5 | 32 | 100 | 0.023 | 6.0 | 140 | T |
| CC12H6A | 6 | 32 | 100 | 0.0155 | 8.0 | 140 | F |
| CC12H7A | 7 | 32 | 100 | 0.011 | 9.0 | 120 | J |
| CC12H8A | 8 | 32 | 100 | 0.007 | 12.0 | 80 | V |
| CC12H10A | 10 | 32 | 100 | 0.0065 | 33 | 90 | U |
| CC12H12A | 12 | 32 | 100 | 0.0045 | 45 | 80 | W |
| CC12H15A | 15 | 32 | 100 | 0.0030 | 40 | 70 | Y |
| CC12H20A | 20 | 32 | 100 | 0.0020 | 50 | 60 | Q |
